One New Aftermarket Replacement 50″ Deck Rebuild Kit
Kit Contains:
(9) Spindle Mounting Bolts
(3) Drive Pulleys
(1) Deck Belt
(1) Flat Idler Pulley
(3) Spindle Assemblies
(3) Lawn Mower Blades
Tech Info For Each Part In The Kit:
Lawn Mower Blade –
Length: 17-3/8″
Width: 2-1/4″
Center Hole: 5 Point Star
Thickness: 0.160″
Replaces Part Numbers: 137380, 532137380, 95-018, 95-018
Spindle Mounting Bolt –
Self-tapping Bolts
Fits B1AY25 & B1RS25 Spindle Assemblies.
Replaces Part Numbers: 138776, 157722, 173984, 173984-A, 532138776, 532157722, 532173984, B1RS5
Drive Pulley –
Outer Diameter: 5-1/6″
Inner Diameter: 9/16″
Fits 42″ Deck models
Steel
Replaces Part Numbers: 129861, 129861, 173436, 532153535, 532173436, 153535, 153535, 173436, 129861, 177865, 173436, 173436 153535, 173436, 153535, 532153535, 129861, 177865, 21546127, 275-284, 3j7, 532129861, 532153535, 532173436, 80-91-050, B1SB7180
Deck Belt –
Color: Brown
Length: 95-1/2″
Thickness: 0.374″
Type: Wrapped
Width: 1/2″
Replaces Part Numbers: 144959, 532 144959, 532 14 49-59, 532 13 84-98, 532138498, 531 30 07-66, 531300766
Flat Idler Pulley –
Flat Idler w/ Flanges
Steel
Drive belt and mower deck pulley on for many 12 through 22 HP front engine tractors
3.875″ (3 7/8”) OD
0.375” (3/8″) ID.
Spindle Assembly –
Includes blade bolt and washers
Does NOT include mounting bolts
Replaces Part Numbers: 137152, 137553, 143651, 176084, 192-653, 192653, 36-51, 532 14 36-51, 5321436-51, 532143651, 9519, B1AY25, RLG143651
Available Individually, In Other Multiples, and Various Kits – Please See Our Other Listings!
