HOUR METER—-The total hour reading display range is 0 to 99999H, 0.1H/1H accuracy.Trackong the total working hours on equipment in real time, the timer data is retained automatically when the equipment is turned off, and the next cycle is accumulated directly CRAFTSMANSHIP —- It is sealed with epoxy resin, waterproof rate is IP68, and it is also shockproof and high temperature resistant to avoid damage during transportation and use INSTALLATION—-The hour meter is easy to install and does not require wiring or connection with the accompanying hardware. Pass the wire through the housing wall and then wind it around the ignition coil to avoid coiling on the wire coil APPLICATION—- Inductive Hour Meter for most gas engine,in instance??Lawn mower, ATV, Motorcycle, Boat, Dirt Ski Track the Service Life of Your Vehicle-Oil Changes, Valve, Adjustments and etc OTHER —- Contains detailed user instruction; patent, CE ROHS certification; 2 years after-sales guarantee and technical support, please feel free to contact if you have any questions
Product :JR-HM006A
Induction design: Wrap the wire around the spark plug 4-5 times to work
Attachment :Product??Cable tie*2??Screws*2??Signal wire component??User manual??White box
1 Hour Meter (TOT) Function
Display shows total running time of machine and remains visible.
The total hours max value is 99999H;Total Hours reading displays from 0 to 9999.9H, 0.1H accuracy;Total Hours reading displays from 10000 to 99999H, 1H accuracy.
The timing starts when the detected signal passes through the spark plug wire. It quickly stops running after the engine is turned off, so it does not mistakenly record excess time.
TOT hours are non-resettable. Automatic clearing when exceeding the maximum value.
2 Other Functions
No battery required and connect to spark plug wire.
Built-in battery: CR2430 270mAh.
Hole diameter: 2.5mm.
Display window size??23.7*10mm.
Waterproof rate: IP68.
