PRODUCT FEATURES—- RPM??MAX RPM??Stroke mode setting. INSTALLATION&FIXED—- Easy to use and hook up by just clamping the alligator clip to the spark plug wire.Tapping Screw fixation and Zip tie fixation??Included installation accessories??. UNIQUE CRAFT—-Adopt potting technology.With good shock resistance and water resistance.The battery is non-replaceable.Waterproof rate: IP68. Widely Applicable—-Used on most engines:2 stroke 1 cylinder / 2 stroke 2 cylinder /2 stroke 3 cylinder / 4 stroke 1 cylinder/4 stroke 2 cylinder/4 stroke 3 cylinder/4 stroke 4 cylinder/4 stroke 5 cylinder/4 stroke 6 cylinder/4 stroke 8 cylinder/4 stroke 12 cylinder/4 stroke 16 cylinder. OTHER —- We provide two-year after-sales guarantee and detailed instructions. Please feel free to consult if you have any related equipment problems during the period.
Product Features:
??RPM??Display actual RPM of operation when engine is on.Accuracy is 10 RPM.Refresh rate is 0.5 second.
??MAX RPM??Flash to display MAX RPM of operation for 5 second after engine is off.
??Stroke mode setting??9 Programmable firing patterns:1P1R;2P1R;3P1R;4P1R;6P1R;8P1R;3P2R;5P2R;1P2R.
Product Parameter:
RPM Range: 0-25000RPM.
Battery type:CR2450 540mAH,service life up to 5 years.
Display window size: 27*16mm.
LCD Screen size: 12.5mm??24.5mm.
Wire length??120mm, 47.3in.
Patent, CE ROHS certification.
Applications:
This tachometer can be used for most equipment.Such as small engines,garden tractor,outboard,chainsaws,snowblower, motorcycle,ATV and etc.
